C Series 12MP
Models include 8mm, 12mm, 16mm, 25mm, 35mm, and 50mm focal length options for industrial vision imaging.
Machine Vision Lenses
Industrial Fixed Focal Length Lenses
SJI supplies own-brand C-mount fixed focal length lenses for machine vision imaging, code reading, positioning, inspection, and measurement applications.
12MP C Series
25MP K Series
C-Mount
Manual Iris / Focus
Key Buying Points
Series12MP C Series and 25MP K Series
MountC-mount fixed focal length lens options
ApplicationsInspection, positioning, measurement, and code reading imaging
Selection focusSensor size, working distance, FOV, and resolution requirement
Product Line
Lens Series Available for Industrial Imaging
The current source material includes two major lens groups. The C Series focuses on 12MP imaging needs, while the K Series covers 25MP, 1.1 inch applications with focal lengths from 12mm to 75mm.
K Series 25MP
1.1 inch 25MP fixed focal lenses with 12mm, 16mm, 25mm, 35mm, 50mm, and 75mm options.
Selection Support
Share camera sensor size, working distance, target FOV, resolution requirement, and installation space.
Model Matrix
Machine Vision Lens Models
| Model | Series | Focal Length | Resolution | Iris | Focus | Mount | Dimensions |
|---|---|---|---|---|---|---|---|
| C0828-SV-12M | C Series | 8mm | 12MP | F2.8-F16 | 0.05m-Inf. | C | Dia.29 x 29.4mm |
| C1228-SV-12M | C Series | 12mm | 12MP | F2.8-F16 | 0.1m-Inf. | C | Dia.29 x 33.5mm |
| C1628-SV-12M | C Series | 16mm | 12MP | F2.8-F16 | 0.1m-Inf. | C | Dia.29 x 34.5mm |
| C2528-SV-12M | C Series | 25mm | 12MP | F2.8-F16 | 0.25m-Inf. | C | Dia.29 x 35.5mm |
| C3528-SV-12M | C Series | 35mm | 12MP | F2.8-F16 | 0.25m-Inf. | C | Dia.29 x 47.5mm |
| C5028-SV-12M | C Series | 50mm | 12MP | F2.8-F16 | 0.3m-Inf. | C | Dia.29.5 x 50.5mm |
| K1228-SV-25M | K Series | 12mm | 25MP | F2.8-F16 | 0.1m-Inf. | C | Dia.59 x 77mm |
| K1628-SV-25M | K Series | 16mm | 25MP | F2.8-F16 | 0.15m-Inf. | C | Dia.42 x 56mm |
| K2528-SV-25M | K Series | 25mm | 25MP | F2.8-F16 | 0.15m-Inf. | C | Dia.35 x 42.8mm |
| K3528-SV-25M | K Series | 35mm | 25MP | F2.8-F16 | 0.2m-Inf. | C | Dia.35 x 45.6mm |
| K5028-SV-25M | K Series | 50mm | 25MP | F2.8-F16 | 0.25m-Inf. | C | Dia.35 x 56.6mm |
| K7528-SV-25M | K Series | 75mm | 25MP | F2.8-F16 | 0.45m-1.9m | C | Dia.35 x 68.5mm |
Recommended Lens Inquiry Information
- Camera sensor size, resolution, and mount type.
- Working distance and required field of view.
- Target object size, inspection precision, and lighting condition.
- Application type: code reading, positioning, measurement, defect inspection, or general imaging.
Supply & Trade Info
MOQConfirm with sales
Lead timeConfirm by focal length, quantity, and stock
WarrantyStandard industrial lens support
DocumentsLens model sheet and selection support available on request
Need lens selection support?
Send the camera sensor size, target field of view, working distance, resolution requirement, and installation limit. SJI can recommend a suitable C-mount lens family.
